Technical data:

• Max. operating pressure: 16 bar

• Max. diff. pressure on the body: 4 bar

• Max. diff. pressure on the seat: 4 bar

• Min. operating temp.: 2 °C (pure water)

Materials:

• Body: DZR (CC752S)

• Bonnet: DZR (CW602)

• Sealings and O-rings EPDM
