Technical data:

• max. operating temperature: 120°C

• min. operating temperature: -20°C

• max. operating pressure: 16 bar

Materials:

• Body: Brass nickel plated

• Spindle: Stainless steel

• Sealings: EPDM

• Connections: Outside threads with cone to connect with compressionunits

• Actuating Thread M28x1,5
