Technical data:

• Power consumption: 3.5 W

• Position accuracy: ±5%

• Manual override: Temporary and permanent disengagement of the gearing latch by means of the rotary knob on the housing

• Running time: 140 s/ 90°

• Degree of protection: IP40

• Ambient temperature range: 0 … + 50 °C

• Media temperature: + 5 ...+ 120 °C (in ball valve)
